Description
4 Series 40 x 160 10 Slot Standard Extrusion is a 4 Series aluminium T slot profile designed for strength, mounting area, and flexibility in large frame builds. This extrusion features 10 open 10mm T slots, with one slot on each 40mm face and four slots on each 160mm face.
4 Series 40 x 160 10 Slot Standard Extrusion is suited to heavy machine frames, workstation bases, guards, enclosures, and industrial support structures. The silver anodised finish gives the profile a smooth, corrosion resistant surface that is easy to keep clean in workshop and production areas.
Product Name: 4 Series 40 x 160 10 Slot Standard Extrusion
Product Code: 1.0416.10.SPRS
Series: 4 Series
Material: Aluminium
Grade: 6063T5
Finish: Anodised
Colour: Silver
Length: Priced per mm, available in any length over 10mm and under 5800mm
KG/M: 3
Compatible With: All SlotPro 4 Series connectors, fixings, accessories, and compatible profile components
Key Features:
• 10 open 10mm T slots for high mounting capacity
• Wide 40 x 160 profile for strong frame construction
• Silver anodised finish for corrosion resistance
• Compatible with SlotPro 4 Series components
• Available cut to length to suit your project
Common Applications:
• Heavy machine frames and workstation bases
• Safety guards and barrier structures
• Modular enclosures and partitions
• Large benches, supports, and industrial frames
• Custom displays and structural frameworks
Need Custom Lengths or Help with Design?
SlotPro offers a cut and mill service. Contact our team for layout assistance, technical support, or help selecting the right components for your build.
