4 Series 40 x 40 4 Slot Standard Powder Coated Yellow Extrusion

4 Series 40 x 40 4 Slot Standard Powder Coated Yellow Extrusion is a high visibility 4 Series aluminium extrusion designed for machine guarding, modular safety structures, workstations, and industrial frame builds. This square profile features four open 10mm T slots, with one slot on each face for mounting SlotPro connectors and accessories.

4 Series 40 x 40 4 Slot Standard Powder Coated Yellow Extrusion is suited to safety zones and industrial environments where visibility, clean presentation, and reliable frame assembly are important. The yellow powder coated finish gives the profile a smooth surface that is easy to clean and helps resist dirt buildup.

Product Name: 4 Series 40 x 40 4 Slot Standard Powder Coated Yellow Extrusion
Product Code: 1.0404.4.SPSSPCY
Series: 4 Series
Material: Aluminium
Grade: 6063T5
Finish: Powder Coated
Colour: Yellow
Slot Size: 10mm
Centre Bore: Ø6.8mm
Length: Priced per mm, available in any length over 10mm and under 5800mm
Weight: 1.5 kg/m
Compatible With: All SlotPro 4 Series connectors and accessories

Key Features:
• High visibility yellow powder coated finish
• Four open 10mm T slots, with one slot on each face
• 40 x 40 aluminium profile for compact frame builds
• Ø6.8mm centre bore for machining
• Compatible with SlotPro 4 Series connectors and accessories
• Available cut to length to suit your project

Common Applications:
• Machine frames
• Workstations
• Safety guarding
• Displays
• Automation structures, including conveyors

Need Custom Lengths or Help with Design?
SlotPro offers a cut and mill service. Contact our team for layout assistance, technical support, or help selecting the right components for your build.
