Wing Hinge Cover Caps

Wing Hinge Cover Caps are press-fit end caps used to complete the SlotPro concealed hinge system. These durable plastic caps snap into each end of the wing hinge and over the Wing Hinge SS Pin, sealing the hinge from dust, debris, and wear while maintaining a clean appearance.

Wing Hinge Cover Caps are compatible with all SlotPro Wing Hinges across the 2, 3, and 4 Series. Hinges, pin, and fasteners are sold separately.

Product Name: Wing Hinge Cover Caps
Product Code: 4.04.WHCC
Series: Universal (2, 3, 4 Series)
Material: Plastic
Colour: Silver
Compatible With: All SlotPro Wing Hinges (2, 3, and 4 Series)

Key Features:
• Protective end caps for wing hinge assemblies
• Prevents dust and debris from entering the hinge
• Provides a clean, professional finish
• Compatible with all SlotPro Wing Hinges and Pins
• Easy press-fit installation

Fixings Required to Make 1 Hinge:
• 2 x 4.0X.WH – Wing Hinge (2, 3, or 4 Series)
• 1 x 4.04.WHP – Wing Hinge SS Pin
• 2 x 4.04.WHCC – Wing Hinge Cover Cap (this product)
• 4 x Roll-in Slot Nuts or T-Nuts
• 4 x Countersink Screws

Installation Tip:
Once the wing hinges and hinge pin are installed, push the cover caps firmly into place at each end to seal the hinge and maintain a clean profile.

Common Applications:
• Modular enclosures and frames
• Electrical or mechanical access panels
• Secure compartments with concealed hinges
• Industrial cabinetry and service housings

Need Custom Lengths or Design Support?
SlotPro provides a full cut and mill service to suit your project. For layout advice or help selecting compatible accessories, contact our team:
