Bolt Hole Fitting Castor Black – 75mm

Bolt Hole Fitting Castor Black – 75mm is a compact swivel bolt hole castor for adding mobility to SlotPro aluminium extrusion frames and light duty assemblies. The 75mm rubber wheel keeps the overall frame height lower while still allowing carts, display stands, and smaller mobile builds to be moved when needed.

Bolt Hole Fitting Castor Black – 75mm is suited to light duty SlotPro projects where a simple bolt hole fitting and non marking rubber wheel are required. It is a practical option for compact frames, retail displays, small benches, and movable aluminium extrusion builds.

Product Name: Bolt Hole Fitting Castor Black – 75mm
Product Code: WCR75/H
Material: Steel castor frame with rubber wheel
Colour: Black
Diameter: 75mm
Max Load: 50kg per castor
Compatible With: Suitable SlotPro aluminium extrusion frame assemblies

Fixings Required:
M10 bolt with suitable mounting hardware to suit the frame design.

Key Features:
• 75mm rubber wheel
• Swivel bolt hole fitting
• 50kg load rating per castor
• Compact size for lower height assemblies
• Ball bearing wheel
• Suitable for light duty mobile frames

Installation Tip:
Fit to a suitable mounting point and tighten securely. Check that all castors are aligned and that the total frame load is suitable for the selected castors.

Common Applications:
• Compact mobile frames
• Light duty workshop trolleys
• Movable display stands
• Small carts
• Retail display frames
• Aluminium extrusion assemblies
