Description
4 Series 40 x 40 4 Slot Standard Extrusion is a 4 Series aluminium extrusion designed for medium to heavy duty frame builds. This square profile features four open 10mm T slots, with one slot on each 40mm face for mounting SlotPro connectors, panels, brackets, and accessories.
4 Series 40 x 40 4 Slot Standard Extrusion is suited to machine frames, safety guarding, workstations, tool benches, displays, signage, and conveyor systems. The silver anodised finish gives the profile a smooth, corrosion resistant surface that is easy to clean and helps reduce dirt buildup.
Product Name: 4 Series 40 x 40 4 Slot Standard Extrusion
Product Code: 1.0404.4.SPSS
Series: 4 Series
Material: Aluminium
Grade: 6063T5
Finish: Anodised
Colour: Silver
Length: Priced per mm, available in any length over 10mm and under 5800mm
KG/M: 1.5
Compatible With: All SlotPro 4 Series connectors, fixings, accessories, and profile components
Key Features:
• Four open 10mm T slots, with one slot on each 40mm face
• 40 x 40 aluminium profile for medium to heavy duty frame builds
• Smooth anodised finish for easy cleaning and corrosion resistance
• Compatible with SlotPro 4 Series connectors and accessories
• Available cut to length to suit your project
Common Applications:
• Machine frames
• Safety guarding
• Workstations and tool benches
• Displays and signage
• Automation and conveyor systems
Need Custom Lengths or Help with Design?
SlotPro offers a cut and mill service. Contact our team for layout assistance, technical support, or help selecting the right components for your build.
