Description

30 x 90 SlotPro 8 Slot Standard Extrusion is a 3 Series T-slot profile with a 8mm T-slot on each face. The surface of the profile is resistant to dirt and debris build-up because it is smooth and easy to clean. The 30mm x 90mm T-slot profile is compatible with the 3 series connectors and other components. The 30mm x 90mm profile is a great choice for machine frames and guards, workstations, displays and other small to medium applications. The eight open T-slots are useful for mounting SlotPro components and accessories.

Download the CAD file for this product in .step format here.

  • Product Code: 1.0309.8.SPRS
  • Series: 3 Series
  • Material: Aluminium
  • Grade: 6063T5
  • Finish: Anodised
  • Colour: Silver
  • KG/M: 1.2
  • Length: Priced per MM, available in any length over 10mm and under 5800mm.
  • Common Uses: Machine frames and displays.
